S172D-26 by teledyne relays

S172D-26

Teledyne Relays

Electromechanical Relay 26.5VDC 1.6KOhm 1A DPDT (9.6x10.42x9.4)mm SMD Centigrid Commercial Relay ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TELEDYNE RELAYS part S172D-26 is an electromechanical relay that operates at a voltage of 26.5VDC. This relay has a resistance of 1.6KOhm and is capable of handling a current of 1A. It features a double pole double throw (DPDT) configuration and is designed to be surface mounted using the SMD Centigrid technology. With dimensions of 9.6x10.42x9.4mm, this compact commercial relay is reliable and suitable for a wide range of applications.

Search Keywords: S172D26

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Teledyne Relays
Part No:
S172D-26
RoHS:
Yes
HTS:
8536410020
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
26.5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
1 A
Mounting:
Surface Mount
Operating Temperature:
-55 to 85 °C
Dimension:
9.6 x 10.42 x 9.4 mm
Termination Style:
Solder
Coil Current:
16.56 mA
Contact Form:
2 Form C

IN STOCK: 14

Ships today, if you order in

On Order: 100   can ship 4/30/26

Factory Lead-Time 29 Weeks

Price (USD)

Qty
Unit Price
1
$154.582
5
$142.820
10
$123.899
15
$123.281
25
$122.663
50 +
$122.055
