S172D-5 by teledyne relays

S172D-5

Teledyne Relays

Electromechanical Relay - 5VDC - 64Ohm - 1A - DPDT - (9.6x10.42x9.4)mm - SMD Centigrid Commercial Relay. ...

Datasheet
RoHS Non-Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The S172D-5, S172D Series surface mount Centigrid® relay is an ultra miniature, hermetically sealed, armature relay for commercial applications. Its low profile height (0.47) and 0.1" grid spaced terminals make it an ideal choice where extreme packaging density and⁄or close PC board spacing are required. The specially formed leads are pre-tinned to make the relays ideal for all types of surface mount solder reflow processes. The S172D relay has an internal discrete silicon diode for coil transient suppression.

Search Keywords: S172D5

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Teledyne Relays
Part No:
S172D-5
RoHS:
No
HTS:
8536410020
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
1 A
Mounting:
Surface Mount
Operating Temperature:
-55 to 85 °C
Dimension:
9.6 x 10.42 x 9.4 mm
Termination Style:
Solder
Coil Current:
78.12 mA
Contact Form:
2 Form C
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 167

Can Ship immediately

On Order: 174   can ship 4/20/26

Factory Lead-Time 25 Weeks

Price (USD)

Qty
Unit Price
1
$114.114
5
$112.435
10
$102.681
15
$102.166
25
$101.651
50 +
$87.272
Log in for special pricing
Click for Quote
