Image is representational - see mfr. specs

RB2577F

Sta-Con® 250 Series Female Disconnects - Nylon Open Top Insulated 90 Degree Flag Female Disconnect Terminal - Wire Range #16-#14AWG - Material Copper - Tin-Plated Finish - Color Blue ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The RB2577F is a nylon-insulated open-top 90-degree flag female terminal for wire range #16 - #14 AWG. The unique construction of the female disconnect offers long-term dependability. The brazed seam serrated barrel provides maximum tensile strength. Length .80 inches, .72 inches width, maximum insulation .190 inches, tab size .250x.032. The terminal is high-conductivity electrolytic copper, electro-tin plated, with color-coded insulation for easy installation. Recommended tool ERG4001.

Product Highlights:

Potential Applications:

Search Keywords: RB2577F

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Thomas & Betts

Part No:

RB2577F

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
