RE6-14 by thomas - betts
Image is representational - see manufacturer specifications
Thomas & Betts Authorized Distributor

RE6-14

Sta-Con® Nylon-Insulated Large Ring Terminal - Wire Size #6AWG - Material Copper - Tin-Plated Finish - Color Blue - Bolt Hole 1/4 Inch - Voltage Rated 600V ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The RE6-14 is a large ring terminal insulated with high dielectric-strength nylon for wire size #6 AWG. These ring terminals have funneled barrel entry, deep internal serrations, and brazed or overlapping seams. Length 1.65 inches, .49 inches width, maximum insulation .420 inches, bolt hole 1/4 inches The terminal is high-conductivity electrolytic copper, electro-tin plated, with color-coded insulation, rated for 105°C max temperature. Installing tool ERG4007.

Search Keywords: RE614

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Thomas & Betts
Part No:
RE6-14
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
20
  Different packaging options available.  See Alternatives

IN STOCK: 222

Ships today, if you order in

Minimum Order Quantity: 20

Multiple: 20

Factory Lead-Time 5 Weeks

Price (USD)

Qty
Unit Price
20
$7.34
40
$6.74
100
$5.95
260
$5.76
500
$5.75
1,000
$5.73
2,500 +
$5.72
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides

Accessories

ERG4007

Ergonomic Hand Tool for Crimping RD, RE Insulated Terminals
