F-16X

The F-16X is a chassis-mount, single secondary power transformer designed for a 115V, 50/60 Hz primary input. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The F-16X is a chassis-mount power transformer featuring a single secondary winding. It is designed to operate with a 115V, 50/60 Hz primary and delivers a maximum power of 18.9 VA. The secondary is rated for 6.3V with a center tap (VCT) at 3.0 Amps and has a typical voltage regulation of 15% from full load to no load. Constructed with UL recognized, Class B (130° C) rated materials, the unit is 100% hipot tested with 2500V insulation between windings and the core. Its reliable design makes it suitable for various electronic applications requiring a low-voltage AC source.

Search Keywords: F16X

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Triad Magnetics
Part No:
F-16X
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504314035
COO:
PH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Primary Configuration:
Single
Primary Side Voltage:
115 V
Secondary Configuration:
Single
Secondary Side Voltage:
6.3 V
Secondary Side Current:
3000 mA
Power Rating:
18.9 VA
Mounting:
Flange Mount
Dimension:
84.1 x 50.8 x 49.2 mm

IN STOCK: 30

Can Ship immediately

Manufacturer Stock: 17   can ship 11/16/26

Minimum Order Quantity: 5

Factory Lead-Time 18 Weeks can ship 3/5/27

Price (USD)

Qty
Unit Price
5
$16.21
25
$15.48
50
$14.82
100
$13.58
250
$13.37
500
$12.76
1,000 +
$12.73
