VPS24-1000 by triad magnetics
Image is representational - see mfr. specs

VPS24-1000

Triad Magnetics

The VPS24-1000 is a 25VA chassis-mount power transformer with dual primary and secondary windings for versatile voltage configurations. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The VPS24-1000 is a chassis-mount power transformer with a maximum power rating of 25VA. It features dual primary windings for operation at 115V or 230V AC (50/60Hz) and dual secondary windings that can be connected in series for 24V CT at 1.0A or in parallel for 12.0V at 2.0A. The unit is designed with dual bobbin construction and provides 4000VAC isolation between the primary and secondary windings for enhanced safety. With UL, CSA, and TUV agency approvals, this transformer is suitable for a wide range of general purpose and information technology equipment applications.

Search Keywords: VPS241000

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Triad Magnetics
Part No:
VPS24-1000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504314035
COO:
PH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Primary Configuration:
Dual
Primary Side Voltage:
230,115 V
Secondary Configuration:
Dual
Secondary Side Voltage:
24,12 V
Secondary Side Current:
1000,2000 mA
Power Rating:
25 VA
Mounting:
Flange Mount
Dimension:
71.4 x 57.2 x 58.7 mm

IN STOCK: 33

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
5
$19.44
25
$14.96
50
$14.17
100
$13.14
250
$12.63
500
$12.33
1,000 +
$12.27
