BCN104AB1000F7
TT Electronics/BI MagneticsThick Film Chip Array - 4 Isolated Resistors - 100 Ohms ±1% 63mW per Element - ±200ppm/°C - SMD 1mm x 2mm - Tape&Reel ...
DESCRIPTION
BCN104AB1000F7 is a thick film chip resistor array from the BCN Series, featuring four isolated 0402 resistor elements mounted on an alumina substrate with ruthenium oxide resistive material. The device measures 2.00 mm in length and 1.00 mm in width with a height of 0.45 mm, incorporating square convex terminations and 100% tin conductor plating for reliable soldering. It operates across an ambient temperature range of -55°C to +155°C with a limiting element voltage of 25 V and maximum overload voltage of 63 V, supporting resistance values with 1% or 5% tolerance. The component is RoHS compliant (Pb-free), AEC-Q200 qualified, and available in a sulphur-resistant version, making it suitable for automotive, industrial, and high-reliability applications requiring compact multi-resistor integration.
Search Keywords: BCN104AB1000F7
SPECIFICATIONS
IN STOCK: 20,000
Can Ship immediately
MOQ for In Stock Qty: 1613
MOQ for out of Stock Qty: 1613
Factory Lead-Time 9 Weeks
Datasheet
