260-4T5E

The 260-4T5E is an epoxy-insulated cup clip heat sink with a tapped base, designed for TO-5 case style semiconductors. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 260-4T5E is an epoxy-insulated cup clip from the 260 Series, designed to provide thermal management for TO-5 case style semiconductors. It features a tapped base with a #4-40 UNC thread and a depth of 0.093 inches. Constructed with a beryllium copper cup and a brass base, both finished with black ebonol 'C', this clip provides a thermal resistance of 14° C/W. The epoxy insulation offers a breakdown voltage of 500 VAC, making this component suitable for applications requiring reliable heat dissipation and electrical isolation in a continuous operating temperature range of -73°C to +149°C.

Search Keywords: 2604T5E

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Wakefield
Part No:
260-4T5E
Alias/AKA:
2604T5E
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8473309100
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Device Cooled:
TO-5
Attachment Method:
Clip
Dimension:
9.4 x 9.7 mm
Thermal Resistance:
14 °C/W
Finish:
Black Ebonol

IN STOCK: 117

Can Ship immediately

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$27.91
5
$26.99
10
$23.73
25
$22.78
50
$21.64
100
$20.17
300 +
$19.82
