1748220000 by weidmuller
Image is representational - see mfr. specs

1748220000

Weidmuller

Conn Terminal Block SKT 16 POS 3.5mm Crimp ST Cable Mount 10A Box ...

Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued & Replaced
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The WEIDMULLER part 1277920000 is a PCB plug-in connector designed for easy and reliable connection on circuit boards. It features a female plug with a pitch size of 3.50 mm and comes with 16 poles, offering ample connection options. The connector utilizes a PUSH IN spring connection system, ensuring quick and secure wire termination. With a maximum clamping range of 1.5 mm², it can accommodate various wire sizes. The connector comes in a convenient box packaging, providing adequate protection during transportation and storage.

Search Keywords: 1748220000

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Weidmuller
Part No:
1748220000
Alias/AKA:
1748220000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
48
Type:
Terminal Block
Mounting:
Cable Mount
Gender:
SKT
Termination Method:
Crimp
Pitch:
3.5 mm
Number of Circuits:
8
Maximum Voltage Rating:
300 V
Maximum Current Rating:
10 A
Wire Size:
16-28 AWG
Operating Temperature:
-50 to 100 °C
Life Cycle:
Discontinued & Replaced
  This product is discontinued, but still in stock

IN STOCK: 1

Ships today, if you order in

Buy all 1 in-stock or the regular minimum order quantity of 5

Stock lot only: 1

Minimum Order Quantity: 5

Price (USD)

Qty
Unit Price
1
$9.313
5
$8.467
48
$7.849
96
$7.735
144
$7.622
288
$7.509
528
$7.395
1,008 +
$7.282
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
RECOMMENDED REPLACEMENT
1277920000
1277920000
VIEW PRODUCT
