586-105111S1 by white rodgers / emerson
Image is representational - see manufacturer specifications
White Rodgers / Emerson Authorized Distributor

586-105111S1

Contactor - SPST- NO - 200A - Coil: 12VDC 21Ohms - (Formerly known as 586-902) ...

View Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The WHITE-RODGERS 586-105111 ("S1" suffix if present is an internal storage/handling packaging reference) formerly known as the WHITE-RODGERS/STANCOR 586-902, is an Electromechanical Relay designed for general purpose applications. With a coil voltage of 12VDC and a resistance of 21Ohm, this relay offers a reliable and efficient solution for various control and switching operations. It features a single pole, single throw normally open configuration with a contact rating of 200A normally open and 100A normally closed. The compact dimensions of 93.675mm x 83.82mm x 71.044mm make it suitable for installations with space constraints. This relay is equipped with a flange for easy mounting and is a trusted choice for industrial, automotive, and HVAC applications requiring a robust and versatile relay solution.

Search Keywords: 586105111S1

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
White Rodgers / Emerson
Part No:
586-105111S1
Alias/AKA:
586-105111B1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410060
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Operating Temperature:
-40 to 65 °C
DC Coil Voltage:
12 V
Maximum Pick-Up Voltage:
8.04 VDC
Coil Current:
571.43 mA
Coil Resistance:
21 Ohm
Type:
General Purpose Relay
Mounting:
Flange Mount
Led Indicator:
No
Contact Arrangement:
SPST-NO
Relay Construction:
Non-Latching
Product Weight:
737.09 g
Push to Test Button:
No
Termination Style:
Screw Terminal
Seal:
Sealed
Contact Form:
1 Form A
Family:
586
Maximum Current Rating:
200(NO)/100(NC) A
Dimension:
93.675 x 83.82 x 71.044 mm
Contact Material:
Silver Cadmium Oxide
Coil Suppression Diode:
No

IN STOCK: 102

Can Ship immediately

Buy all 102 in-stock or the regular minimum order quantity of 125

Stock lot only: 102

MOQ for In Stock Qty: 125

MOQ for out of Stock Qty: 125

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
1
$153.839
125
$139.853
250
$71.431
375
$48.626
500 +
$47.648
