25.340.3353.0 by wieland electric
Image is representational - see manufacturer specifications
Wieland Electric Authorized Distributor

25.340.3353.0

The 25.340.3353.0 is a 3-pole, 5 mm pitch pluggable connector with a spring clamp system for wire termination. ...

View Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 25.340.3353.0 is a 3-pole pluggable connector from the fasis family, designed for creating a disconnectable wiring interface with compatible DIN rail terminal blocks. It features a screwless spring clamp termination system for fast and reliable connections, accepting fine-stranded wires from 0.13 to 1.5 mm² and solid wires up to 2.5 mm². This connector is rated for 250V and 16A according to VDE standards, and 300V / 15A per UL specifications. As part of a modular system, it provides a flexible solution for control cabinet wiring where quick component replacement is beneficial.

Search Keywords: 2534033530

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Wieland Electric
Part No:
25.340.3353.0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85366990
COO:
DE
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Type:
Rising Cage Terminal Block
Body Orientation:
Right Angle
Gender:
F
Mounting:
Cable Mount
Pitch:
5.08 mm
Number of Contacts:
3
Maximum Voltage Rating:
300 V
Maximum Current Rating:
15 A
Termination Method:
Screw
Operating Temperature:
N/A

IN STOCK: 504

Can Ship immediately

Minimum Order Quantity: 25

Factory Lead-Time 3 Weeks

Price (USD)

Qty
Unit Price
25
$1.55
250
$1.26
500
$1.19
1,000
$1.14
2,500
$1.10
5,000
$1.07
7,500
$1.06
10,000 +
$1.05
Log in for special pricing

Tools/3D Models

Product Guides
