57.504.0055.2 by wieland electric
Image is representational - see mfr. specs

57.504.0055.2

Wieland Electric

Insulated Header for PC Boards ...

Datasheet
RoHS Compliant
Packaging
Accessories
End of Life: Final orders must be placed by 05/01/2026
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

57.504.0055.2 is a feed-through terminal block with screw connection designed for junction boxes and DIN rail applications. It accommodates fine stranded wire from 0.5–4 mm² or solid wire from 0.5–6 mm² (equivalent to No. 22–10 AWG), with a rated voltage of 800 V (8 kV impulse, 3 kV surge) and 600 V UL/CSA ratings. The block features a width of 6 mm and wire strip length of 9 mm, with a current rating of 32 A at 800 V and 30–35 A at 600 V. This terminal block is compliant with EN 60 947-7-1 and DIN VDE 0611 T1 standards, and is commonly used in electrical distribution systems, control panels, and industrial junction boxes where reliable screw-based wire termination is required.

Search Keywords: 5750400552

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Wieland Electric
Part No:
57.504.0055.2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
End of Life:
Final orders must be placed by 05/01/2026
  End of Life: Final orders must be placed by 05/01/2026

IN STOCK: 798

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 3 Weeks

Price (USD)

Qty
Unit Price
100
$0.872
300
$0.749
1,000
$0.680
2,500
$0.634
5,000
$0.631
7,500
$0.628
10,000
$0.625
15,000 +
$0.622
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
