Z5.530.4625.0 by wieland electric
Image is representational - see mfr. specs

Z5.530.4625.0

Wieland Electric

Conn Unshrouded Header HDR 16 POS 5mm Solder ST Thru-Hole ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Z5.530.4625.0 is a 16-pole pluggable PC board connector with 5.00 mm spacing designed for reliable electrical interconnections in industrial and electronic applications. The connector features a rated current of 8 A and rated voltages of 200 V/4 kV/3 (Overvoltage category III), 250 V/4 kV/2 (Overvoltage category II), and 1000 V/4 kV/1 (Overvoltage category I) according to VDE 0110 standards. It accommodates wire connections ranging from 0.14 to 4.0 mm² solid or 0.14 to 2.5 mm² fine stranded conductors, with a solder pin diameter of 1.3 mm and bore hole of 1.6 mm for PCB mounting. The insulating housing is constructed from polycarbonate (PC) gray material rated UL 94-V-0, with tin-plated brass contact pins and nickel-plated brass clamping screws ensuring superior corrosion resistance and long-term reliability. This connector is ideal for control systems, automation equipment, and industrial machinery where secure, space-efficient interconnections are required.

Search Keywords: Z553046250

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Wieland Electric
Part No:
Z5.530.4625.0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Unshrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
5 mm
Number of Contacts:
16
Maximum Voltage Rating:
N/A
Maximum Current Rating:
8 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 1,119

Can Ship immediately

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
50
$1.421
250
$1.156
500
$1.131
1,000
$1.075
2,500
$1.030
5,000
$1.025
7,500
$1.020
10,000 +
$1.015
Suppliers Standard Package
