2065-10-9 by winchester/kings
Image is representational - see mfr. specs

2065-10-9

Winchester/Kings

Conn BNC PL 0Hz to 3GHz 75Ohm Crimp ST Cable Mount Gold ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 2065-10-9 is a 75-ohm BNC connector manufactured by Winchester/Kings, designed for professional video and RF applications requiring high-frequency signal integrity. It operates across a frequency range of DC to 6 GHz with a nominal impedance of 75 ohms and is rated for a working voltage of 500 VRMS, delivering excellent return loss performance across the frequency spectrum (less than -30 dB up to 1.5 GHz, less than -22 dB up to 3.0 GHz, and less than -18 dB up to 6.0 GHz). The connector features a Teflon insulator, silicone rubber gasket, beryllium copper spring washer and outer contact, and commercial bronze K-grip sleeve, with gold-plated center contacts and tarnish-resistant nickel finish on other metal parts. It is compliant with the SMPTE 424M (3G-SDI) specification and is designed for use with Belden 1694A cable, making it ideal for broadcast video, professional audio/video systems, and high-frequency RF applications where signal fidelity and impedance matching are critical.

Search Keywords: 2065109

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Winchester/Kings
Part No:
2065-10-9
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
BNC
Impedance:
75 Ohm
Operating Frequency:
0 to 3 Hz to GHz
Gender:
PL
Mounting:
Cable Mount
Body Orientation:
Straight
Terminate To:
Coaxial Cable
Termination Method:
Crimp
Operating Temperature:
N/A
Dimension:
30.98 x 14.47 mm

IN STOCK: 6,485

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 25

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$10.91
10
$10.89
25
$10.86
50
$8.15
75
$7.60
100 +
$7.45
Suppliers Standard Package
