2065-2-9 by winchester/kings
Image is representational - see mfr. specs

2065-2-9

Winchester/Kings

Conn BNC PL 0Hz to 3GHz 75Ohm Crimp ST Cable Mount Gold ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 2065-2-9 is a BNC connector plug assembly designed for terminating Belden 9259 coaxial cable in RF and video applications. It features a 75 ohm nominal impedance with a working voltage rating of 500 VRMS and operates across a frequency range from DC to 3 GHz. The connector is constructed with a Teflon insulator, beryllium copper outer contact, commercial bronze K-grip sleeve, and brass components, with center contacts gold-plated per MIL-G-45204 and all other metal parts finished in Kings tarnish-resistant nickel (TR-5). This assembly is commonly used in broadcast, telecommunications, and test equipment applications where reliable RF signal transmission and impedance matching are critical.

Search Keywords: 206529

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Winchester/Kings
Part No:
2065-2-9
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
BNC
Impedance:
75 Ohm
Operating Frequency:
0 to 3 Hz to GHz
Gender:
PL
Mounting:
Cable Mount
Body Orientation:
Straight
Terminate To:
Coaxial Cable
Termination Method:
Crimp
Operating Temperature:
N/A
Dimension:
30.73 x 14.47 mm

IN STOCK: 894

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
5
$7.87
25
$6.91
50
$6.85
100
$6.80
300
$6.77
500
$4.83
1,000
$4.31
2,500 +
$4.27
Suppliers Standard Package
