EA2-24NU by world products

EA2-24NU

World Products

Electromechanical Relay 24VDC 2.88KOhm 1A DPDT (14.2x9.2x5.4)mm THT Signal Relay ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The WORLD PRODUCTS EA2-24NU is an electromechanical relay designed for various applications. With a voltage rating of 24VDC, this relay offers excellent performance and reliability. It features a resistance of 2.88KOhm, allowing for efficient signal transmission. The double pole double throw (DPDT) configuration ensures versatile functionality. This compact relay measures 14.2x9.2x5.4mm, making it suitable for space-restricted installations. It offers through-hole technology (THT) for easy and secure mounting. Whether used in industrial automation, telecommunications, or other industries, the EA2-24NU relay delivers exceptional electrical switching performance.

Search Keywords: EA224NU

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
World Products
Part No:
EA2-24NU
RoHS:
Yes
HTS:
8536490050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
40
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
1 A
Mounting:
Through Hole
Operating Temperature:
-40 to 85 °C
Dimension:
14.2 x 9.2 x 5.4 mm
Termination Style:
PC Pin
Coil Current:
8.33 mA
Contact Form:
2 Form C

IN STOCK: 345

Ships today, if you order in

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 250

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
25
$2.297
50
$2.276
100
$2.204
250
$2.081
500
$2.009
750
$1.998
1,000 +
$1.813
