EP2F-B3G1ST by world products

EP2F-B3G1ST

World Products

Electromechanical Relay 12VDC 225Ohm 30A DPDT (23.8x16.2x16)mm THT Automotive Relay ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The WORLD PRODUCTS part EP2F-B3G1ST is a high-quality electromechanical relay designed for automotive applications. It operates at 12VDC with a coil resistance of 225Ohm and a current rating of 30A. With its DPDT (Double Pole Double Throw) configuration, it provides versatile switching capabilities for various circuits. The compact size of (23.8x16.2x16)mm allows for easy installation in tight spaces. This Through Hole Technology (THT) relay is reliable and durable, ensuring optimal performance and longevity. Suitable for automotive electronics, this relay is an essential component for electrical systems in vehicles.

Search Keywords: EP2FB3G1ST

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
World Products
Part No:
EP2F-B3G1ST
RoHS:
Yes
HTS:
8536490050
COO:
PH
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Contact Form:
DPDT (2 Form C)
Relay Construction:
Non-Latching
Max Contact Current:
30A
Coil Voltage:
12 VDC
Coil Current:
53.3 mA
Coil Resistance:
225 Ohm
Contact Material:
Silver Oxide
Must Operate Voltage:
6.5 VDC
Must Release Voltage:
0.9 VDC
Operate Time:
5 ms
Seal:
Sealed
Mounting:
Through Hole
Termination Style:
PC Pin
Dimension:
23.8 x 16.2 x 16 mm
Operating Temperature:
-40 to 85 °C
Packaging:
N/A

IN STOCK: 1,468

Ships today, if you order in

Minimum Order: 10

Factory Lead-Time 16 Weeks

Price (CAD)

Qty
Unit Price
10
$10.658
100
$6.983
250
$6.616
500
$6.356
1,000
$6.324
2,500
$6.293
5,000
$6.263
7,500 +
$6.232
