ADH200120 by zettler magnetics
Image is representational - see mfr. specs

ADH200120

Zettler Magnetics

power, low volt, pc mount transformer ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

ADH200120 is a PCB-mounted power transformer rated at 1.1VA with dual 115/230V primary windings (±10% @ 50/60Hz) and dual secondary windings that can be configured for either series or parallel connection. The transformer features a maximum temperature rise of 45°C, excitation current of 25mA maximum, and high-pot insulation ratings of 2500Vrms (primary to secondary) and 1500Vrms (primary/secondary to core) for 1 minute. In series connection, it delivers 120V output at 9.2mA, while in parallel connection it provides 60V at 18.3mA, making it suitable for various low-voltage AC applications. The device is constructed with Class B insulation system (ZM-130-5) and meets UL506 safety standards for general-purpose transformers in US and Canada markets.

Search Keywords: ADH200120

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Zettler Magnetics
Part No:
ADH200120
Unit of Measure:
Per Each
RoHS:
Yes
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1

IN STOCK: 990

Ships today, if you order in

Minimum Order Quantity: 10

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
10
$2.40
50
$2.18
250
$2.09
500
$2.05
1,000
$2.01
2,500
$1.85
5,000
$1.83
7,500 +
$1.82
Log in for special pricing Click for Quote Price Match Request
