ADH20016 by zettler magnetics
Image is representational - see mfr. specs

ADH20016

Zettler Magnetics

Power Transformer 2500Vrms 1.1VA 8Term. PC Pin Thru-Hole ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

ADH20016 is a PCB-mounted power transformer rated at 1.1VA with dual 115/230V primary windings and dual secondary windings. The transformer operates at 50/60Hz with ±10% voltage tolerance and delivers 8V at 140mA in parallel connection or 16V at 70mA in series connection. It features a maximum temperature rise of 45°C, excitation current of 25mA maximum, and meets UL506 safety standards with Class B insulation system (ZM-130-5). High-pot testing is rated at 2500Vrms for primary-to-secondary and 1500Vrms for primary/secondary-to-core. This transformer is ideal for general-purpose power supply applications, industrial control systems, and consumer electronics requiring dual-voltage input capability with flexible output configurations.

Search Keywords: ADH20016

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Zettler Magnetics
Part No:
ADH20016
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504314035
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Package Type:
TUBE

IN STOCK: 1,555

Ships today, if you order in

Minimum Order Quantity: 10

Multiple: 10

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
10
$3.94
50
$3.53
100
$3.45
250
$3.40
500
$3.31
1,000
$3.27
2,500
$3.22
5,000 +
$3.21
Suppliers Standard Package
