ADH30012 by zettler magnetics
Image is representational - see manufacturer specifications
Zettler Magnetics Authorized Distributor

ADH30012

Power Transformer 2500Vrms 2.4VA 8Term. PC Pin Thru-Hole ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

ADH30012 is a 2.4VA power transformer designed for PCB mounting with dual 115/230V primary windings and dual secondary windings that can be configured in series or parallel. The transformer operates at input voltages of 115/230V ±10% at 50/60Hz frequency, with secondary output options of 6.3V at 400mA (parallel connection) or 12.6V at 200mA (series connection). It features a maximum temperature rise of 45°C, excitation current of 25mA maximum, and meets UL506 safety standards with Class B insulation system rated for 130°C. The high-pot ratings of 2500Vrms (primary to secondary) and 1500Vrms (primary/secondary to core) ensure robust electrical isolation. This transformer is ideal for general-purpose power supply applications, industrial control systems, and consumer electronics requiring reliable step-down voltage conversion with flexible output configurations.

Search Keywords: ADH30012

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Zettler Magnetics
Part No:
ADH30012
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504314035
COO:
VN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Package Type:
TUBE

IN STOCK: 612

Ships today, if you order in

MOQ for In Stock Qty: 10

MOQ for out of Stock Qty: 510

Multiple: 10

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
10
$5.17
100
$3.82
250
$3.74
510
$3.71
1,020
$3.70
1,530
$3.69
2,040 +
$3.68
