0E1300E0 by zf electronic systems

0E1300E0

ZF Electronic Systems

Switch Snap Action N.O./N.C. SPDT Button Quick Connect/Faston 15A 250VAC 1118.55VA 4.17N Screw Mount ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ZF Electronics Corp E13-00E is a versatile Snap Action Switch that features a Single Pole Double Throw (SPDT) configuration with a button actuator. This high-performance switch is rated for 15A @ 125/250VAC and 2A @ 48VDC, making it suitable for a wide range of applications. The E13-00E is designed for easy installation with Quick Connect terminals and screw mount capabilities, ensuring reliability and efficiency in your electrical systems.

Product Highlights:

  • 5 current ratings
  • Choice of actuator styles
  • 3 terminal types (optional screw terminals available — consult factory)
  • 3 contact arrangements
  • Long-life coil spring mechanism
  • High-temperature 150°C and 200°C available on select models (consult factory)
  • Includes E13, E14, E29, E30 and G13 Series.

Search Keywords: 0E1300E0

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
0E1300E0
RoHS:
Yes
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Package Type:
Box
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Thermoplastic Nylon/Button
Contact Rating @ Voltage:
1118.55 A
Maximum Movement Differential:
0.38 mm
Operating Force:
4.17 N
Termination Style:
Quick Connect
Dimension:
67.12 x 16.26 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 1,214

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
5
$5.974
50
$4.213
100
$3.924
250
$3.739
500
$3.512
1,000
$3.399
2,500
$3.327
5,000 +
$2.905
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
