DB1C-B1AA by zf electronic systems

DB1C-B1AA

ZF Electronic Systems

Switch Snap Action N.O./N.C. SPDT Button Quick Connect 6A 250VAC 80VDC 1.47N Screw Mount ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ZF Electronics Corp DB1C-B1AA is a versatile snap action switch that allows for quick connect installation. With a single pole double throw (SPDT) configuration, this switch is capable of both normally open (N.O.) and normally closed (N.C.) positions. It can handle current up to 6A at 250VAC and 80VDC. Featuring a screw mount design, it ensures secure and reliable installation. This switch also provides a tactile button for easy and convenient operation, making it ideal for various applications requiring precise and dependable switching.

Search Keywords: DB1CB1AA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
DB1C-B1AA
RoHS:
Yes
HTS:
8536509040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Box
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Polybutylene Terephthalate/Button
Contact Rating @ Voltage:
6@250VAC@EN A
Maximum Movement Differential:
0.1 mm
Operating Force:
1.47 N
Termination Style:
Quick Connect
Dimension:
20 x 6.45 x 18.95 mm
Body Orientation:
Straight
IP Rating:
IP50

IN STOCK: 0

On Order: 4,980   can ship 12/29/25

Minimum Order: 10

Factory Lead-Time 30 Weeks

Price (USD)

Qty
Unit Price
10
$3.481
100
$2.132
250
$1.864
500 +
$1.720
