DB2C-C1AA

Switch Snap Action N.O./N.C. SPDT Button PC Pins 10.1A 250VAC 80VDC 186.42VA 2.45N Thru-Hole ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

DB2C-C1AA is a subminiature snap action switch from the DB Series, designed for precision switching applications requiring high repeat accuracy. This SPDT (Single Pole Double Throw) switch features an EN rating of 10(1.5)A at 250VAC and a UL rating of 10.1A at 125/250VAC, with 0.051" x 0.020" (1.3 x 0.5 mm) PCB straight terminals. The switch operates over a temperature range of -40°C to 85°C and offers a mechanical life of up to 10 x 106 cycles. Constructed with a thermoplastic PET base (UL 94 V-0), PBT cover, and silver-nickel or gold crosspoint contacts, it provides IP50 protection. This RoHS compliant switch is suitable for applications requiring reliable, high-current switching with international approvals.

Search Keywords: DB2CC1AA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
DB2C-C1AA
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509040
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1200
Package Type:
BOX
Mounting:
PCB Mount
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Polybutylene Terephthalate/Button
Contact Rating @ Voltage:
186.42@UL A
Maximum Movement Differential:
0.1 mm
Operating Force:
2.45 N
Termination Style:
PC Pins
Dimension:
20 x 6.45 x 12.48 mm
Body Orientation:
Straight
IP Rating:
IP50

IN STOCK: 948

Can Ship immediately

Minimum Order Quantity: 25

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$1.824
25
$1.658
100
$1.483
250
$1.411
500
$1.401
1,200
$1.349
3,600
$1.339
6,000
$1.277
8,400 +
$1.267
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides
