DB3C-A1AA by zf electronic systems
Image is representational - see manufacturer specifications
ZF Electronic Systems Authorized Distributor

DB3C-A1AA

Switch Snap Action N.O./N.C. SPDT Button Solder 0.1A 250VAC 80VDC 1.47N Screw Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The ZF Electronics Corp part DB3C-A1AA is a versatile and reliable switch designed for a wide range of applications. This snap action switch offers a single pole double throw (SPDT) configuration with normally open (N.O.) and normally closed (N.C.) contacts. With a solder connection type and a current rating of 0.1A at 250VAC and 80VDC, this switch is suitable for low voltage and low current applications. It is also equipped with a 1.47N actuation force and features a convenient screw mount design for easy installation. Whether used in industrial, automotive, or consumer electronics, the DB3C-A1AA switch delivers reliable performance and durability.

Search Keywords: DB3CA1AA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
DB3C-A1AA
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1200
Package Type:
BOX
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Polybutylene Terephthalate/Button
Contact Rating @ Voltage:
0.1@250VAC 80VDC@EN A
Maximum Movement Differential:
0.1 mm
Operating Force:
1.47 N
Termination Style:
Solder
Dimension:
20 x 6.45 x 15 mm
Body Orientation:
Straight
IP Rating:
IP50

IN STOCK: 9,829

Can Ship immediately

Minimum Order Quantity: 25

Factory Lead-Time 30 Weeks

Price (USD)

Qty
Unit Price
25
$2.63
100
$2.49
250
$2.44
500
$2.21
1,200
$1.74
3,600
$1.73
6,000
$1.72
8,400 +
$1.71
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
