DB3C-B1RC by zf electronic systems

DB3C-B1RC

ZF Electronic Systems

Switch Snap Action N.O./N.C. SPDT Roller Lever Quick Connect 0.1A 250VAC 80VDC 0.54N Screw Mount ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ZF Electronics Corp part DB3C-B1RC is a high-quality snap action switch that offers reliable performance in various applications. Its compact design and quick-connect terminals make it easy to install. This versatile switch features a single-pole, double-throw (SPDT) configuration with a roller lever for smooth operation. It can handle a current rating of up to 0.1A at 250VAC or 80VDC, making it suitable for both low and high voltage circuits. Additionally, its robust construction ensures durability and long-lasting performance. The DB3C-B1RC switch is conveniently mountable with screws, offering versatile installation options.

Search Keywords: DB3CB1RC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
DB3C-B1RC
RoHS:
Yes
HTS:
8536509065
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Stainless Steel/Polybutylene Terephthalate/Roller Lever
Contact Rating @ Voltage:
0.1@250VAC 80VDC@EN A
Maximum Movement Differential:
0.6 mm
Operating Force:
0.54 N
Termination Style:
Quick Connect
Dimension:
20 x 6.45 x 29.65 mm
Body Orientation:
Straight
IP Rating:
IP50
  Possible Replacement options available.  See Alternatives

IN STOCK: 10,306

Can Ship immediately

On Order: 7,035   can ship 8/19/26

Minimum Order: 10

Factory Lead-Time 50 Weeks

Price (CAD)

Qty
Unit Price
10
$5.022
100
$3.767
250
$3.491
560
$3.293
1,120 +
$2.771
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
