E14-00H by zf electronic systems

E14-00H

ZF Electronic Systems

Snap Action Switch - SPDT - Lever - 25A@125/250VAC 2A@48VDC - Quick Connect - Screw Mount ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ZF Electronics Corp E14-00H is a versatile and high-quality snap action switch designed for various applications. With a single-pole double-throw (SPDT) configuration, this switch is equipped with a reliable lever mechanism. It can handle impressive current ratings of up to 25A@125/250VAC and 2A@48VDC, making it suitable for both high and low voltage applications.The switch features quick connect terminals, allowing for easy and efficient installation. Moreover, it is designed to be securely mounted using screws, ensuring stability and durability. With its robust construction and dependable performance, the ZF Electronics Corp E14-00H snap action switch is an ideal choice for a wide range of industrial, automotive, and household applications.

Product Highlights:

  • 5 current ratings
  • Choice of actuator styles
  • 3 terminal types (optional screw terminals available — consult factory)
  • 3 contact arrangements
  • Long-life coil spring mechanism
  • High-temperature 150°C and 200°C available on select models (consult factory)
  • Includes E13, E14, E29, E30 and G13 Series.

Search Keywords: E1400H

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
E14-00H
RoHS:
Yes
HTS:
8536509040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
672
Package Type:
Box
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Thermoplastic Nylon/Lever
Contact Rating @ Voltage:
1491.4 A
Maximum Movement Differential:
1.27 mm
Operating Force:
2.79 N
Termination Style:
Quick Connect,Faston
Dimension:
69.18 x 16.26 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 2,308

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 336

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
5
$8.487
100
$5.603
250
$5.253
336
$5.202
672
$5.150
1,008
$5.099
1,344 +
$5.047
Suppliers Standard Package
Log in for special pricing
Click for Quote

Tools/3D Models

Product Guides
