E72-40AT by zf electronic systems
Image is representational - see manufacturer specifications
ZF Electronic Systems Authorized Distributor

E72-40AT

The E72-40AT is a sealed, subminiature snap-action switch with a button actuator and silver alloy contacts. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Box Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The E72-40AT is a sealed, subminiature snap-action switch from the E72 series, featuring a button actuator. It is rated for 10.1A at 125/250VAC under UL1054 and has a minimum electrical life of 6,000 operations. This switch operates with a maximum force of 300 grams, features a maximum movement differential of 0.004 inches, and is designed to function reliably across a temperature range of -40°C to +85°C. Built with a hi-temp thermoplastic case and a water-resistant hydrin boot, this moisture-resistant switch is ideal for applications requiring durability and environmental protection.

Product Highlights:

  • Moisture resistant
  • 3 contact arrangements
  • Long life coil spring mechanism
  • Choice of button or hinged actuator
  • 10-inch, 16 gauge leads attached
  • Custom wire and harness designs available upon request

Search Keywords: E7240AT

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ZF Electronic Systems
Part No:
E72-40AT
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536507000
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
200
Package Type:
Box
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
High Temperature Thermoplastic Nylon/Button
Contact Rating @ Voltage:
186.42@UL A
Maximum Movement Differential:
0.1 mm
Operating Force:
2.94 N
Termination Style:
Wire Lead
Dimension:
23.24 x 9.78 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 1,490

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 250

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
5
$16.24
50
$13.24
100
$11.62
250
$11.23
500
$11.03
750
$10.84
1,000 +
$10.80
