ABLS2-24.000MHZ-D4YF-T
AbraconCrystal - HC/49US (AT49) -24.000MHZ (+/-) 30ppm - 18pF - -40°C to +85°C - SMD - Tape&Reel ...
DESCRIPTION
ABLS2-24.000MHZ-D4YF-T is a low-profile HC/49US (AT49) surface mount microprocessor crystal designed for compact applications requiring reduced height. The device features a compact footprint of 11.4 × 4.7 × 3.3 mm with a fundamental frequency of 24.000 MHz and is suitable for RoHS-compliant reflow soldering. It operates over a temperature range of -40°C to +85°C with frequency stability of ±30 ppm and a frequency tolerance of ±50 ppm at +25°C, providing tight stability for microprocessor and wireless applications. The crystal is hermetically sealed with no moisture sensitivity (MSL N/A) and features a maximum shunt capacitance of 7 pF, load capacitance of 18 pF, and equivalent series resistance of 40 O. This device is ideal for computers, modems, microprocessors, and wireless applications where space constraints and reliable timing are critical.
Search Keywords: ABLS224000MHZD4YFT
SPECIFICATIONS
IN STOCK: 4,650
Ships today, if you order in
Minimum Order Quantity: 1000
Multiple: 1000
Factory Lead-Time 10 Weeks
Price (USD)
Tools/3D Models
Product Guides
Datasheet
