2036-07-SM-RPLF

Gas Discharge Tube (GDT) - 75VDC - 10kA DC - 10A AC - 2pF -Solder. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Reel Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 2036-07-SM-RPLF is a Precision Gas Discharge Tube Surge Protector, ideal for board level protection of high bandwidth applications such as xDSL, cable broadband and high speed Ethernet, due to its high energy handling capability, long and stable life performance and low capacitance of less than 2pF. High surge current rating, low insertion loss. Leadless, surface mount for economical assembly. Operating temperature range is from -55 to 85°C.

Search Keywords: 203607SMRPLF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
2036-07-SM-RPLF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Reel
Maximum Impulse Sparkover Voltage@100V/s:
250 V
Maximum Impulse Sparkover Voltage@1KV/s:
525 V
Typical DC Sparkover Voltage@100V/s:
75 V
Number of Electrodes:
3
Packaging:
Tape and Reel
Failsafe Protection:
No
Typical Impulse Discharge Current @ 8/20us @ 10Times:
10 kA
DC Sparkover Voltage Tolerance:
±20 %

IN STOCK: 13,826

Ships today, if you order in

Minimum Order Quantity: 250

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
250
$1.094
500
$1.072
1,000
$1.038
3,000
$0.970
5,000
$0.934
8,000
$0.932
10,000
$0.930
15,000 +
$0.928
Reel Package
