Image is representational - see mfr. specs

1896/5C-SL002

Alpha Wire

Multi-Conductor Cable Polyvinyl Chloride 5 Conductors 20AWG 6.14mm 300VAC - Slate - 152.4m (500ft)/Spool ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

1896/5C-SL002 is a five-conductor control cable designed for general-purpose wiring applications requiring reliable signal transmission. The cable features 20 AWG tinned copper conductors (7/28 stranding) with individual 0.016" nominal PVC insulation, color-coded per Alpha Wire Color Code D (black, red, white, green, orange), and assembled with a minimum of 4.4 twists per foot. The outer jacket is 0.020" nominal PVC with a slate color and rated for operation from -20°C to +80°C with a maximum voltage rating of 300V RMS. This cable meets UL AWM/STYLE 2509, CM, and VW-1 standards at 80°C, as well as CSA CMG and FT4 certifications, making it suitable for industrial control systems, instrumentation, and general-purpose interconnect applications where compact, multi-conductor routing is required.

Product Highlights:

Potential Applications:

Search Keywords: 18965CSL002

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

1896/5C-SL002

Alias/AKA:

1896/5C-SLATE-500

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
