5855-YL005 by alpha wire
Image is representational - see manufacturer specifications
Alpha Wire Authorized Distributor

5855-YL005

Hook-up Wire 22AWG 1.3mm Silver Plated Copper - Yellow - 600V Bulk - 30.48m (100ft)/Spool ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 5855-YL005 is a single-conductor hookup wire designed for high-temperature and high-voltage applications. It features a 22 AWG (19/34) stranded copper conductor with a nominal 0.010" wall PTFE insulation, providing an outer diameter of 0.050" ± 0.005". The wire is rated for 600V RMS and operates reliably across a temperature range of -60°C to 200°C, meeting UL AWM/Style 1213 VW-1 and MIL-W-16878/4 (Type E) specifications. With a maximum pull tension of 5.9 lbs and a bend radius of 10× cable diameter, this wire is ideal for laboratory equipment, test instrumentation, and industrial control systems where durability and thermal stability are essential.

Search Keywords: 5855YL005

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alpha Wire
Part No:
5855-YL005
Alias/AKA:
5855-YELLOW-100
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544493080
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Size:
22 AWG
Bunch Stranding:
19x34
Conductor Material:
Silver Plated Copper
Cable Diameter:
1.39 mm
Maximum Voltage Rating:
600 VAC
Operating Temperature:
-60 to 200 °C
Color:
N/R
  Different packaging options available.  See Alternatives

IN STOCK: 0

On Order: 6   can ship 11/8/27

Factory Lead-Time 53 Weeks

Price (USD)

Qty
Unit Price
1
$158.49
5
$154.09
10
$151.98
20
$151.60
50
$145.97
100 +
$142.23
Log in for special pricing
