6710-RD001

Alpha Wire

Hook Up Wire - Stranded - 28 (7/36) AWG - 600V - mPPE - Red - 1000 ft - Tinned Copper ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

6710-RD001 is a halogen-free single conductor hookup wire designed for general-purpose electrical connections. It features a 28 AWG (7/36) tinned copper conductor with a nominal diameter of 0.015 inches and modified polyphenylene ether insulation with a 0.0095" wall thickness, resulting in an overall insulation diameter of 0.034 ± 0.002 inches. The wire is rated for 600 VRMS with an operating temperature range of -40 to 105°C, and meets UL AWM/STYLE 11028 (VW-1) and CSA International C(RU) AWM I A/B FT1 certifications. Electrical properties include a nominal inductance of 0.06 µH/ft and conductor DC resistance of 65 O/1000ft at 20°C. This RoHS-compliant wire is suitable for applications requiring halogen-free materials and compliance with IEC 60332-2 flame behavior standards.

Product Highlights:

Potential Applications:

Search Keywords: 6710RD001

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

6710-RD001

Alias/AKA:

6710-RED-1000

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
