6712-GR005

Alpha Wire

Hook Up Wire - Stranded - 24 (7/32) AWG - 600V - mPPE - Green - 100 ft - Tinned Copper ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

6712-GR005 is a single-conductor hookup wire designed for general-purpose electrical connections. It features a 24 AWG (7/32) tinned copper conductor with a nominal diameter of 0.024 inches, insulated with a 0.0095-inch wall of modified polyphenylene ether material for an overall insulation diameter of 0.043 ± 0.002 inches. The wire is rated for 600 VRMS with an operating temperature range of -40 to 105°C, and offers a conductor DC resistance of 25 O/1000ft at 20°C. It is halogen-free and meets UL AWM/STYLE 11028 (VW-1), CSA International C(RU) AWM I A/B FT1, and IEC 60332-2 flame behavior standards. This wire is ideal for applications requiring reliable performance, RoHS compliance, and halogen-free construction in industrial and electronic equipment.

Product Highlights:

Potential Applications:

Search Keywords: 6712GR005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

6712-GR005

Alias/AKA:

6712-GREEN-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
