EC11E1530401 by alps electric

EC11E1530401

Alps Electric

Mechanical Encoder Rotary Incremental Flat 0.007N.m Straight Quadrature Digital Square Wave 15PPR Through Hole PC Pin ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ALPS ELECTRIC EC11E1530401 is a high-quality mechanical encoder designed for rotary incremental applications. This flat-shaft encoder offers a precise and reliable solution for various control and navigation systems. With a low operating torque of 0.007N.m, it ensures smooth and accurate rotation. The encoder provides a straight quadrature digital square wave output, configurable for 15 pulses per revolution (PPR). Its through-hole design and PC pin terminals make it easy to mount and connect, ensuring convenient integration into your electronic projects.

Search Keywords: EC11E1530401

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alps Electric
Part No:
EC11E1530401
RoHS:
Yes
HTS:
8543704500
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1200
Package Type:
Tray
Built-in Switch:
No
Bearings:
N/A
Body Orientation:
Straight

IN STOCK: 1,987

Ships today, if you order in

Minimum Order: 25

Factory Lead-Time 12 Weeks

Price (CAD)

Qty
Unit Price
25
$7.610
250
$5.957
500
$5.605
1,200
$5.574
3,600
$5.544
6,000
$5.513
8,400
$5.498
10,800 +
$5.467
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
