EC11E1820402 by alps electric

EC11E1820402

Alps Electric

Mechanical Encoder Rotary Incremental Flat 10mN-m Straight Quadrature Digital Square Wave 18PPR Through Hole PC Pins ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ALPS ELECTRIC EC11E1820402 is a mechanical rotary incremental flat encoder designed for precise rotational control in various applications. This encoder offers reliable performance with a low torque of 10mN-m, making it ideal for fine-tuned adjustments. Featuring a straight quadrature digital square wave output, it provides accurate feedback of the rotary position. With an 18 pulse-per-revolution (PPR) resolution, it ensures improved precision for position sensing.The EC11E1820402 is designed for easy installation, thanks to its through-hole PC pins that securely mount it onto circuit boards. This encoder is suitable for a wide range of applications, including industrial machinery, robotics, automotive systems, and consumer electronics.Overall, the ALPS ELECTRIC EC11E1820402 is an excellent choice for applications requiring reliable, precise, and compact rotary control. Its high-quality construction and efficient design make it a trusted solution for demanding engineering projects.

Search Keywords: EC11E1820402

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alps Electric
Part No:
EC11E1820402
RoHS:
Yes
HTS:
8543908885
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2400
Package Type:
Tray

IN STOCK: 1,660

Ships today, if you order in

Minimum Order: 25

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
25
$2.894
100
$2.544
250
$2.348
500
$2.194
2,400
$2.070
4,800
$2.060
7,200
$2.050
9,600 +
$2.039
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes
