AZ822-2C-48DSE by american zettler

AZ822-2C-48DSE

American Zettler

Sub-Mini DIP Relay 48VDC coil DPDT ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AMERICAN ZETTLER AZ822-2C-48DSE is a versatile Sub-Mini DIP Relay with a 48VDC coil. This compact relay features a DPDT (Double Pole Double Throw) configuration, making it ideal for a variety of electronic applications where space is limited. With reliable performance and a durable construction, this relay is a dependable choice for your electrical switching needs.

Search Keywords: AZ8222C48DSE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ822-2C-48DSE
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
4000
Package Type:
Tube
Relay Construction:
Non-Latching
DC Coil Voltage:
48 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-55 to 90 °C
Dimension:
20.2 x 10 x 11.5 mm
Termination Style:
PC Pin
Coil Current:
6.3 mA
Contact Form:
2 Form C

IN STOCK: 830

Can Ship immediately

Minimum Order: 25

Multiple: 25

Factory Lead-Time 9 Weeks

Price (CAD)

Qty
Unit Price
25
$3.782
250
$2.511
500
$2.236
1,000
$2.113
2,500
$2.037
5,000
$1.884
7,500 +
$1.869
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
