AZ970E-1A-12D by american zettler
Image is representational - see mfr. specs

AZ970E-1A-12D

American Zettler

40AMP Automotive Relay 12VDC coil SPST-NO ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AZ970E-1A-12D is a 45 A automotive relay designed for high-inrush switching applications in compact form factor. It features a 12 VDC nominal coil with 8.4 VDC must-operate voltage and 21.3 VDC maximum continuous rating, with a coil resistance of 90.0 O (±10%). The relay provides Form A (SPST) contact configuration with a maximum switched current of 45 A and maximum switched power of 560 W at 150 VDC maximum switched voltage. Operating characteristics include a 5 ms typical operate time and 3 ms typical release time at nominal coil voltage, with a minimum life expectancy of 5×106 operations. The relay operates across -40°C to +125°C ambient temperature range, withstands 0.062" displacement amplitude vibration at 10–55 Hz and 10 g shock, and is housed in a P.B.T. polyester enclosure with tinned copper alloy terminals. This relay is ideal for automotive electrical systems requiring reliable high-current switching with vibration and shock resistance.

Search Keywords: AZ970E1A12D

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ970E-1A-12D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
300
Package Type:
Tray
Contact Form:
SPST-NO (1 Form A)
Relay Construction:
Non-Latching
Coil Voltage:
12 VDC
Coil Current:
133.33 mA
Coil Resistance:
90 Ohm
Contact Material:
Silver Tin Oxide
Must Operate Voltage:
8.4 VDC
Must Release Voltage:
0.72 VDC
Operate Time:
5 ms
Seal:
Unsealed
Mounting:
Through Hole
Termination Style:
PC Pin
Operating Temperature:
-40 to 125 °C

IN STOCK: 0

On Order: 1,200   can ship 7/29/26

Minimum Order Quantity: 25

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
25
$1.88
100
$1.58
300
$1.46
600
$1.40
1,200
$1.34
2,700
$1.31
5,100
$1.19
7,500 +
$1.17
Suppliers Standard Package
