LCC17A3W3PM2N0 by amphenol communications solutions (acs)
Image is representational - see mfr. specs

LCC17A3W3PM2N0

Amphenol Communications Solutions (ACS)

Conn D-Subminiature PIN 3Power POS 6.86mm Solder Cup ST Panel Mount 3 Terminal 1 Port ...

Datasheet
RoHS Compliant
BOX Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

LCC17A3W3PM2N0 is a high-current D-SUB connector featuring a 3-position, 3-power arrangement with pin-style contacts and solder cup termination designed to accept up to 8 AWG wire. The connector delivers a current rating of 55 A per contact with a maximum contact resistance of 0.25 milliohms, and supports a dielectric withstanding voltage of 1500V DC. It operates reliably across a temperature range of -40°C to +105°C and is constructed with RoHS-compliant materials including tin-over-nickel plated steel shells, glass-reinforced engineering thermoplastic insulator (UL 94V-0), and gold-plated copper alloy contacts. This connector is ideal for high-power applications in industrial equipment, power distribution systems, and heavy-duty electrical assemblies where robust, low-resistance connections are essential.

Search Keywords: LCC17A3W3PM2N0

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol Communications Solutions (ACS)
Part No:
LCC17A3W3PM2N0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
60
Package Type:
BOX
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
Pin
Termination Method:
Solder Cup
Shell Size:
N/A
Number of Contacts:
3Power
Contact Plating:
Gold over Nickel
Operating Temperature:
-40 to 105 °C

IN STOCK: 66

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
5
$16.35
25
$14.81
60
$13.74
120
$12.99
300
$12.64
540
$12.61
1,020 +
$12.47
Suppliers Standard Package
