325150

Name: 325150
Brand: Te Connectivity Amp Brand
SKU: 10359474
Price: 41.2 USD
Availability: OutOfStock

The 325150 is a Pre-Insulated Diamond Grip (PIDG) flanged spade tongue terminal for terminating 12-10 AWG wire. ...

View Datasheet

Ask the Datasheet

RoHS Compliant

BOX Packaging

Certificate of Compliance

DESCRIPTION

The 325150 is a PIDG (Pre-Insulated Diamond Grip) spade tongue terminal designed for reliable wire termination. It features a closed barrel design, accepts a wire size range of 12-10 AWG, and is suitable for a #6 or M3.5 stud. The terminal is constructed from tin-plated copper with yellow nylon insulation, providing support and protection for the connection. Rated for a maximum of 300 VAC, it can accommodate a maximum insulation diameter of 6.35 mm. The straight, flanged spade tongue shape ensures a secure connection, making it suitable for various industrial and commercial electrical applications.

Product Highlights:

Terminal Shape = Spade Tongue, Flanged
Receptacle Style = Straight
Body Style = PIDG
Barrel Type = Closed Barrel
Wire/Cable Type = Regular Wire

Potential Applications:

Search Keywords: 325150

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

325150

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
