86093968114755V1LF by amphenol communications solutions (fci)
Image is representational - see mfr. specs

86093968114755V1LF

Amphenol Communications Solutions (FCI)

Conn DIN 41612 RCP 96 POS 2.54mm Solder ST Thru-Hole Tray ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 86093968114755V1LF is a DIN 41612 Style-C female receptacle connector featuring 96 contacts arranged in 3 rows with a 2.54 mm pitch per row. The insulator is constructed from thermoplastic polyester (UL94V-O, grey) and can withstand lead-free wave soldering temperatures of 250–265°C. Contacts are made from copper alloy with gold over nickel plating in the active zone and tin (pure matte) over nickel plating in the termination zone for the lead-free version. Electrically, the connector is rated for 1.5 A at 20°C with a maximum current of 2 A, operates across a temperature range of -55°C to +125°C, and provides contact resistance of = 20 mO and insulation resistance of = 10? MO. The connector features insertion and extraction forces of = 0.94 N and = 0.15 N per contact respectively, meeting DIN 41612 Class 2 performance specifications. This connector is ideal for industrial instrumentation, data acquisition systems, and embedded applications requiring reliable high-density interconnection with lead-free compliance.

Search Keywords: 86093968114755V1LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol Communications Solutions (FCI)
Part No:
86093968114755V1LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
IN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
352
Package Type:
TRAY
Type:
DIN 41612
Gender:
RCP
Body Orientation:
Straight
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
96
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C

IN STOCK: 244

Can Ship immediately

On Order: 1,056   can ship 8/28/26

Minimum Order Quantity: 10

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
10
$4.24
50
$2.67
100
$2.62
352
$2.54
704
$2.51
1,056
$2.50
2,816
$2.49
5,280 +
$2.48
Suppliers Standard Package
