D25P24A4GV00LF by amphenol communications solutions (fci)
Image is representational - see mfr. specs

D25P24A4GV00LF

Amphenol Communications Solutions (FCI)

Conn D-Subminiature PIN 25 POS 2.76mm Solder ST Thru-Hole 25 Terminal 1 Port ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

D25P24A4GV00LF is a 25-pin D-subminiature connector header designed for direct PCB board mounting with a screw lock mechanism. The connector features a shell size 25 with dimensional specifications including an overall length (A) of 53.03 mm ±0.38 mm, width (B) of 47.04 mm ±0.12 mm, and height (C) of 39.12 mm ±0.10 mm. The product is rated for a performance level PL1 with a minimum of 500 operations, ensuring reliable mechanical cycling. The connector is lead-free compliant and designed for straight-soldered PCB mounting with continuous electrical contact capability. This connector is commonly used in industrial control systems, data acquisition equipment, and legacy computer peripherals requiring robust D-subminiature connectivity.

Search Keywords: D25P24A4GV00LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol Communications Solutions (FCI)
Part No:
D25P24A4GV00LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
IN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
120
Package Type:
TRAY
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
M
Termination Method:
Solder
Shell Size:
B
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 125 °C

IN STOCK: 718

Ships today, if you order in

Minimum Order Quantity: 120

Multiple: 120

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
120
$2.48
360
$2.30
600
$2.27
1,080
$2.17
2,520
$2.11
5,040
$2.06
7,560
$2.03
10,080 +
$2.02
Suppliers Standard Package
