901-9511-1

The 901-9511-1 is a straight SMA plug connector for flexible cables, featuring a stainless steel body with gold plating. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 901-9511-1 is a 50-ohm straight SMA plug designed for termination with flexible cables from Cable Group C1 (RG-55, 142, 223, 400). It features a durable stainless steel body and center contact, both with gold plating for excellent conductivity and corrosion resistance. The connector utilizes a crimp termination for the cable braid and a solder termination for the center contact, ensuring a secure and reliable connection. Built in accordance with MIL-C-39012, this high-performance connector operates from DC to 12.4 GHz and is ideal for instrumentation, telecommunications, and general-purpose cable assembly applications.

Search Keywords: 90195111

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
901-9511-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BAG
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 12.4 Hz to GHz
Gender:
Plug
Mounting:
Cable Mount
Body Orientation:
Straight
Terminate To:
Flexible Cable
Termination Method:
Crimp
Operating Temperature:
-65 to 165 °C
Dimension:
27.9 x 7.92 x 7.92 mm

IN STOCK: 453

Can Ship immediately

Manufacturer Stock: 6   can ship 11/16/26

Minimum Order Quantity: 5

Factory Lead-Time 14 Weeks can ship 2/8/27

Price (USD)

Qty
Unit Price
5
$24.10
10
$21.35
25
$20.28
50
$19.31
100
$18.05
250
$16.94
500 +
$15.40
