PM16P1620A30
Anderson Power ProductsContact PIN Crimp ST Cable Mount 16-20AWG ...
DESCRIPTION
PM16P1620A30 is a gold-plated pin contact designed for use in the 1x4 auxiliary connector system of SBE®320/SBX®350 power connectors manufactured by Anderson Power Products. This contact is specifically configured for 20-16 AWG wire gauges with a cross-sectional area of 0.75 to 1.0 mm², and is available in three different lengths (Standard Length 7.7 mm, Pre-Mate 9.3 mm, and Post-Mate 6.4 mm) to enable circuit sequencing within auxiliary positions. The contact features gold plating for low resistance and superior electrical performance, with durability rated up to 10,000 mating cycles. These auxiliary contacts support intelligent power switching, CAN bus, and interlock loop circuitry with power capability up to 20 amps per pole, making them ideal for battery management systems, electric vehicle charging infrastructure, and industrial power distribution applications requiring reliable auxiliary signal and control circuits.
Search Keywords: PM16P1620A30
SPECIFICATIONS
IN STOCK: 390
Can Ship immediately
MOQ for In Stock Qty: 10
MOQ for out of Stock Qty: 125
Factory Lead-Time 4 Weeks
Price (USD)
Tools/3D Models
Product Guides
Datasheet
