Image is representational - see mfr. specs

0ZCJ0110FF2E

The 0ZCJ0110FF2E is a 1206 size surface mount PTC (Positive Temperature Coefficient) device designed for overcurrent protection. ...

Datasheet

RoHS Compliant

Reel Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The 0ZCJ0110FF2E is a surface mount PTC from the OZCJ series, designed to provide overcurrent protection in electronic circuits. It features a hold current of 1.10 A and a trip current of 2.20 A, with a maximum voltage rating of 8 Vdc. This device has a fast maximum time-to-trip of 0.30 seconds at 8.00 A and can withstand a maximum fault current of 100 A. It exhibits a low minimum resistance of 0.040 ohms and a typical power dissipation of 0.8 W when in a tripped state. Housed in a 1206 chip package and operating from -40°C to 85°C, it is suitable for overcurrent protection on high-density boards and is both UL and TÜV approved.

Product Highlights:

Potential Applications:

Search Keywords: 0ZCJ0110FF2E

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Bel Power Solutions

Part No:

0ZCJ0110FF2E

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8533408070

COO:

ECCN:

EAR99

Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
