23BR20KLFTR by bi technologies/tt electronics
Image is representational - see manufacturer specifications
BI Technologies/TT Electronics Authorized Distributor

23BR20KLFTR

Res Cermet Trimmer 20K Ohm 20% 0.25W(1/4W) 1(Elec)/1(Mech)Turns 2.6mm (5 X 6.5 X 2.8mm) Gull Wing SMD T/R ...

View Datasheet Ask the Datasheet
RoHS Compliant
Reel Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 23BR20KLFTR is a single-turn sealed trimmer potentiometer designed for precision resistance adjustment in electronic circuits. It features a 4 mm square sealed design with cermet element, rated for 20 kO resistance with ±20% tolerance and 0.25 watts power rating at 70°C. The device operates over a temperature range of -55°C to +125°C with a temperature coefficient of ±100 ppm/°C (or ±250 ppm/°C for values <200 Ohms or >1 Megohm), and provides essentially infinite resolution with 200° nominal electrical travel. Its sealed construction with 85°C Fluorinert ensures reliable performance in harsh environments, with excellent environmental resistance including thermal shock, moisture resistance, and vibration immunity. This trimmer is ideal for calibration and tuning applications in instrumentation, consumer electronics, and industrial control systems where compact size and environmental sealing are required.

Search Keywords: 23BR20KLFTR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
BI Technologies/TT Electronics
Part No:
23BR20KLFTR
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
TW
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Reel
Mounting:
Surface Mount
Number of Turns:
1(Elec),1(Mech) Turns
Termination Style:
Gull Wing
Power Rating:
0.25 (1/4) W
Resistance Value:
20 KOhm
Tolerance:
20 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
5 x 6.2 x 2.54 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 300

Ships today, if you order in

You may purchase all in-stock quantity of 300

Stock lot only: 300

Minimum Order Quantity: 500

Multiple: 500

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
1
$0.7999
500
$0.7272
1,000
$0.6757
2,500
$0.6427
5,000
$0.6170
7,500
$0.6139
10,000
$0.6026
15,000
$0.5995
25,000 +
$0.5974
Reel Package
