206-8ST by cts corporation
Image is representational - see manufacturer specifications
CTS Corporation Authorized Distributor

206-8ST

DIP Switch - Thru Hole - 8 Position - SPST - Standard Actuator - Epoxy Seal - Top Tape Seal ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The CTS CORP part 206-8ST is a high-quality DIP switch designed for reliable and efficient operation. It features an SPST configuration with 8 raised slides for easy switching. With a rating of 0.05A and 24VDC, this switch is suitable for a variety of applications. The switch also offers a long lifespan of 10,000 cycles, ensuring durability and longevity. It is designed for through-hole mounting with 2.54mm pin spacing, making it convenient for PCB installations. The switch is packaged in a tube for easy handling and storage.

Search Keywords: 2068ST

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
CTS Corporation
Part No:
206-8ST
Alias/AKA:
206008ST
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509050
COO:
TW
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
25
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Raised Slide
Actuator Length:
0.89 mm
Number of Positions:
8
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.05@24VDC A
Contact Plating:
Gold
Terminal Pitch:
2.54 mm

IN STOCK: 2,535

Can Ship immediately

On Order: 10,000   can ship 12/2/26
On Order: 10,000   can ship 12/30/26

Minimum Order Quantity: 50

Multiple: 25

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
50
$0.8065
250
$0.5355
500
$0.5176
1,000
$0.5048
2,500
$0.4923
5,000
$0.4911
7,500
$0.4899
10,000 +
$0.4886
