68WR10LF by bi technologies/tt electronics
Image is representational - see manufacturer specifications
BI Technologies/TT Electronics Authorized Distributor

68WR10LF

The 68WR10LF is a 10 Ohm, 3/8-inch square, multiturn cermet trimming potentiometer. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Box Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 68WR10LF is a 10 Ohm, RoHS compliant, multiturn trimming potentiometer from the Model 68 series. It features a cermet resistive element in a 3/8" square package and provides precise adjustment with a nominal electrical travel of 20 turns. Key electrical characteristics include a power rating of 0.5 Watts at 85°C, a resistance tolerance of ±20%, and a temperature coefficient of ±250 ppm/°C. The device is sealed to withstand 85°C Fluorinert® and operates across a temperature range of -55°C to +125°C. Its stability and fine-tuning capability make it ideal for circuit calibration and adjustment in various electronic applications.

Search Keywords: 68WR10LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
BI Technologies/TT Electronics
Part No:
68WR10LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Package Type:
Box
Mounting:
Through Hole
Number of Turns:
20(Elec) Turns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
10 Ohm
Tolerance:
20 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
9.53 x 6.22 x 11.05 mm
Operating Temperature:
-55 to 125 °C

IN STOCK: 2,206

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
100
$1.406
300
$1.281
500
$1.212
1,000
$1.145
2,500
$1.095
5,000
$1.005
7,500
$1.002
10,000 +
$1.000
