78PR25KLF by bi technologies/tt electronics
Image is representational - see mfr. specs

78PR25KLF

BI Technologies/TT Electronics

Res Cermet Trimmer 25K Ohm 10% 1W 22(Elec)Turn 2.79mm (33.53 X 4.95 X 8.13mm) Pin Thru-Hole Box ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 78PR25KLF is a multi-turn trimmer potentiometer designed for precision resistance adjustment in electronic circuits. It features a cermet resistive element with a 1-1/4" rectangular molded plastic housing and side adjustment capability via an adjustment screw. The device offers a standard resistance range from 10 ohms to 2 megohms with ±10% tolerance (±20% for values under 100 ohms), and provides essentially infinite resolution with 22 turns of electrical travel. It is rated for 1.0 watt at 70°C, maximum input voltage of 300 Vdc or rms, and maximum slider current of 100 mA, with dielectric strength of 500 Vrms and insulation resistance of 1,000 megohms minimum. The trimmer is commonly used in instrumentation, calibration circuits, and applications requiring precise resistance tuning with excellent stability and reliability.

Search Keywords: 78PR25KLF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
BI Technologies/TT Electronics
Part No:
78PR25KLF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Box
Mounting:
Through Hole
Number of Turns:
22(Elec) Turns
Termination Style:
Pin
Power Rating:
1 W
Resistance Value:
25 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
33.53 x 4.95 x 8.13 mm
Operating Temperature:
-55 to 125 °C

IN STOCK: 816

Ships today, if you order in

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 25

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
5
$4.45
25
$4.39
50
$4.33
88
$4.26
175
$3.21
263
$3.00
350 +
$2.94
Suppliers Standard Package
