79-1413-12-05 by binder-usa
Image is representational - see manufacturer specifications
Binder-USA Authorized Distributor

79-1413-12-05

M9 IP67 Male cable connector, Contacts: 5, shielded, moulded on the cable, IP67, PUR, black, 5 x 0.25mm², 2 m ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 79-1413-12-05 is an M9 male cable connector from the series 702 subminiature connector line, featuring 5 contacts with shielding and a moulded termination on a 2 m polyurethane (PUR) cable. It is rated for 125 V nominal with a 1500 V rated impulse voltage and carries 3.0 A per contact, with an insulation resistance of =10¹° O and IP67 degree of protection. The connector uses a screw locking system with the shield connected to the threaded ring, operates across -25 °C to 70 °C (fixed cable: -50 °C to 90 °C; moving cable: -25 °C to 90 °C), and supports bending radii of =5× diameter (fixed) and =10× diameter (moving) with over 2 million bending cycles. The cable features 5 conductors of 0.25 mm² (AWG 24) cross-section, is halogen-free, and is commonly used in plant engineering, control systems, and electrical equipment construction where reliable, sealed connectivity is required.

Search Keywords: 7914131205

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Binder-USA
Part No:
79-1413-12-05
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85444290
COO:
HU
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1

IN STOCK: 2

Ships today, if you order in

Manufacturer Stock: 73   can ship 11/2/26

Factory Lead-Time 8 Weeks can ship 12/15/26

Price (USD)

Qty
Unit Price
1
$51.04
5
$49.34
10
$46.64
25
$43.86
50
$41.35
100
$40.21
250 +
$38.13
