Image is representational - see manufacturer specifications
Bourns Authorized Distributor

3009P-1-102LF

Res Cermet Trimmer 1K Ohm 10% 0.75W(3/4W) 15(Elec)Turn 2.36mm (20.57 X 4.83 X 8.98mm) Pin Thru-Hole Tube ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 3009P-1-102LF is a 3/4" rectangular multiturn trimming potentiometer manufactured by Bourns, featuring a stable cermet element with infinite resolution and a resistance value of 1 kO. It operates over a temperature range of -55°C to +125°C with a low temperature coefficient of ±100 ppm/°C, ensuring stable performance across demanding industrial environments. The device is rated for 0.75 watts at 70°C with a maximum voltage of 400 volts, and features sealed construction with mechanical stops and solderable pins for reliable panel mounting. Its compact design, low torque requirement of 5.0 oz-in maximum, and RoHS-compliant tin-plated termination make it ideal for precision trimming applications in instrumentation, control systems, and industrial equipment where long-term stability and environmental resistance are critical.

Search Keywords: 3009P1102LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3009P-1-102LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
TW
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
15(Elec) Turns
Termination Style:
Pin
Power Rating:
0.75 (3/4) W
Resistance Value:
1 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
20.57 x 4.83 x 8.98 mm
Operating Temperature:
-55 to 150 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 900

Ships today, if you order in

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
100
$2.15
300
$1.95
500
$1.81
1,000
$1.67
2,500
$1.64
5,000
$1.56
7,500
$1.55
10,000 +
$1.53
